Motion Sensor Switch DC 12V PIR (Infrared Automatic On Off)

• 100% brand new and high quality.
• Delay shut down automatically in the dark, auto on/off with 15s delay time when you get in/out of the induction
• 3m range
• Suitable for LED Strip control
• Application areas: for automatic lighting corridors, Led light strip, bathrooms, basements, warehouses, garages and other places, automatic ventilation exhaust fan and other electrical automatic control and other functions.
• Temperature compensation: temperature compensation chip, reducing the impact sensing distance by the temperature.

Specification:

• Model: LP-2016
• Material: plastic
• Color: white
• Input lead: 140cm

• Output lead: ~15cm
• Sensor cut out diameter: 18mm
• Sensor size: 49*42.5mm
• Working voltage: DC12V
• Working temp: -20 °C � +50 °C
• Static current: < 30uA
• Output current: 2A
• Time delay: 15s(non-adjustable)
• Induction way: passive
• Induction angle: 120 °
• Induction distance: 3m
