Mean Well ELG-75-12-3Y LED Driver 75W 12V IP67 CV+CC PFC

A premium-grade Mean Well driver for demanding 12V installations. The ELG-75-12-3Y runs in mix mode (constant voltage + constant current) with active PFC, an adjustable ±10% output, and a rugged IP67 metal case rated from −40°C to +90°C — suited to outdoor signage, cold-storage lighting, and professional strip installs. 3-wire input version, backed by a 5-year warranty.

Specifications

• Output: 12V DC, 5A / 75W max · mix mode CV+CC
• Output voltage adjustable ±10%
• Input: 100–305V AC (3-wire)
• Active PFC — meets international energy-efficiency regulations
• IP67 metal case · convection cooled
• Protections: short circuit, over-voltage, over-temperature
• Operating temperature: −40°C to +90°C
• Certified: BSMI, CB, CE, EAC, UL
• Size: 180 × 63 × 35.5 mm, 800 g
• Warranty: 5 years
• 6 month warranty

In the box

• 1 × Mean Well ELG-75-12-3Y LED driver

Sizing tip: 75W runs about 10m of 7.2W/m LED strip with headroom.

Contact us for bulk discounts, product variations or custom orders
