LED solid light strip - 12V 480 led/m x 1m
Couldn't load pickup availability
Shipping Policy
Shipping Policy
Return policy
Return policy
Brand new, high quality LED strip sold per meter, amazing looking effect as no diffuser required! Superior to other light strips with the solid light effect.
We can supply up to 5m continuous lengths with cable soldered on one end. 5m will have cable soldered on both ends. Please contact us for multiple or custom lengths.
Requires 12V power supply not included.
COB LED Strip Specifications:
Product Name: | COB LED Strip Light |
Model: | ADW-COB12VX-CCT |
LED Light Source: | COB |
LED QTY/M: | 480 |
Power: | 9-12W/m |
Input Voltage: | 12V |
CCT: | 2900-3100K, 4000-4500K, 6000-6500K |
CRI: | >80, >90 |
LM/W: | 80-120LM/W |
Lumen Output/Meter: | 420LM~1680LM |
PCB Thickness: | 2oz |
PCB Color: | White |
Tape: | 3M 300LSE tape on the back |
Length per reel: | 5M |
Standard Connector: | 20AWG red/black cable on the end |
Length of Cuttable: | 50mm |
PCB width: | 8mm |
LED Strip Dimension: | (Width)*1.6mm(Height)*Length |
Length: | 5000mm (16.4ft) per roll |
Length of Connection Cable: | 150mm length |
LED Beam Angle: | 180° |
Work Temperature: | -20~60° |
Working Humidity: | 40%-70%RH |
Working Lifetime: | 30,000+ hours |
Warranty: | 3 Years |
What’s the difference between COB LED and SMD LED?
The full name of COB is the Chip On Board: directly package the chip on the circuit board. See the following picture:
Superior to typical LED strips
COB LED Strip, 480leds/m DC12V, Length of Cuttable: 50mm, PCB Width: 5mm (8mm, 10mm for optional)
Thanks for choosing to shop with Sparts NZ (locally owned and operated).
Visit us online for our extended range, custom orders and bulk pricing options.
Share
5.0 / 5.0
(6) 6 total reviews
COB-12V-RED-1m












Used this LED strip to repair the brake high-light on my car.
Couldn't source the actual Honda lamp replacement.
Very bright and worked well.
Good price and fast delivery.
Excellent leds ,recommended to all led lovers
Ordered these strips for our new 3d printed lights and even got a phone call asking about the length - fantastic customer surface and stick boy do these strips stick well the the surface they are being applied to. 10/10 for product and service.
Brilliant lights, only one I use for my projects.
Super fast delivery. Thank you
